MG droneIFF
Encrypted . Long Range . World Spectrum
Identification Friend or Foe (IFF) systems is used to identify friendly drone from unidentified drone. As unmanned aerial vehicles (UAVs) or drones have proliferated in both military and civilian airspace, both operators and controllers require the need for an efficient IFF systems that is adapted for security use.
Cryptography
Encrypted beacons with challenge-response authentication
Long Range , Low Power
Zoning control
Geo-Fencing Enforcement
Compliant RF solutions for global region transmission.
Why MG droneIFF ?
MG droneIFF
Purposely build for military / security drone identification
Strong encryption and authentication
Low latency with long range communication
Geo fencing alerts with MG tacticalC2
Scalability for swarms and teaming
Remote ID or Drone ID
Open source code that are supported by many vendors for compliance purpose
It is not build with any security features thus are subjected to jamming and spoofing
Very limited range
Specification
Device UID
12 - character hex string
GNSS
GPS, GLONASS, BDS, Galileo, NAVIC, QZSS multi-system joint positioning
Broadcast Rate
1 msg/sec (configurable)
Payload Encryption
AES 128 ECB
Challenge Payload
Supported
Geo - Fencing Support
Circular / rectangular zones
Operating Frequency
200 to 960 Mhz (Regulatory Approval)
Range
up to 10km (Urban / Line Of Sight)
433 / 868 / 915 Mhz (Standard)
Weight
50 gm
Battery Life
more than 3hrs
