MG droneIFF

Encrypted . Long Range . World Spectrum

Identification Friend or Foe (IFF) systems is used to identify friendly drone from unidentified drone. As unmanned aerial vehicles (UAVs) or drones have proliferated in both military and civilian airspace, both operators and controllers require the need for an efficient IFF systems that is adapted for security use.

Cryptography

Encrypted beacons with challenge-response authentication

Long Range , Low Power

Zoning control

Geo-Fencing Enforcement

Compliant RF solutions for global region transmission.

Why MG droneIFF ?

MG droneIFF

Purposely build for military / security drone identification

Strong encryption and authentication

Low latency with long range communication

Geo fencing alerts with MG tacticalC2

Scalability for swarms and teaming

Remote ID or Drone ID

Open source code that are supported by many vendors for compliance purpose

It is not build with any security features thus are subjected to jamming and spoofing

Very limited range

Specification

Device UID

12 - character hex string

GNSS

GPS, GLONASS, BDS, Galileo, NAVIC, QZSS multi-system joint positioning

Broadcast Rate

1 msg/sec (configurable)

Payload Encryption

AES 128 ECB

Challenge Payload

Supported

Geo - Fencing Support

Circular / rectangular zones

Operating Frequency

200 to 960 Mhz (Regulatory Approval)

Range

up to 10km (Urban / Line Of Sight)

433 / 868 / 915 Mhz (Standard)

Weight

50 gm

Battery Life

more than 3hrs

Comparison
